Copyright © 2004 by Studio Technologies, Inc., all rights reservedwww.studio-tech.com50012-1004, Issue 1User GuideIssue 1, October 2004This User Guide

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 11can either go only to the XLR connec-tor shells, or to both the connector

Issue 1, October 2004 Model 41 User GuidePage 12 Studio Technologies, Inc. Safety Warning: The Model 41 does not contain an AC mains disconnect swit

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 13Audio IntegrityAt this stage the Model 41 should have been installed and t

Issue 1, October 2004 Model 41 User GuidePage 14 Studio Technologies, Inc. on pin 2 of its respective output connector fall below 24 volts DC. This

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 15channels. Should it be necessary, there’s no reason why the headphone outp

Issue 1, October 2004 Model 41 User GuidePage 16 Studio Technologies, Inc. Maintaining Correct Input Signal LevelsThe Model 41’s four 2-channel audi

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 17There’s really only one piece of advice when it comes to understanding how

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 18an output voltage of 30 volts across pins 1 and 2 and can supply a maximum

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 19Superior Power Delivery and Audio QualityAs previously discussed, one of t

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 20051015202530350 50 100 150 200 250Current (mA)Voltage (V)4010Model 41Figur

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 3Table of ContentsIntroduction ...

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 21SpecificationsGeneral Audio:Frequency Response:Pin 2 Outputs (DC with Chan

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 22Interfacing Riedel Artist™ Matrix Intercom Systems with the Model 41 Inter

Issue 1, October 2004 Model 41 User GuidePage 4 Studio Technologies, Inc. This page intentionally left blank.

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 5IntroductionThe Model 41 is designed to create broadcast-standard IFB circu

Issue 1, October 2004 Model 41 User GuidePage 6 Studio Technologies, Inc. IFB circuits provide an effective means of delivering power and two channe

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 7supporting IFB user devices over a wide range of conditions. Connected devi

Issue 1, October 2004 Model 41 User GuidePage 8 Studio Technologies, Inc. be supported. Each of the four Model 41 IFB circuits will support up to si

Model 41 User Guide Issue 1, October 2004Studio Technologies, Inc. Page 9connected. In this situation the left source would be connected to input ch

Issue 1, October 2004 Model 41 User GuidePage 10 Studio Technologies, Inc. If connecting an unbalanced source in this manner results in hum or noise
