Model 74/75 User Guide Issue 2, January 2006

Studio Technologies, Inc. Page 47

for Surround

Function: Input Source and Associated Channels

Byte Value Description

1 F0H System-Exclusive Message

2 00H 1

Byte of Studio Tech ID

3 00H 2

Byte of Studio Tech ID

4 56H 3

Byte of Studio Tech ID

5 07H Product ID (Model 74)

6 01H Function, Input Source and Associated Channels

7 0nH Input Source, range 1-4:

1=Surround A

2=Surround B

3=Stereo A

4=Stereo B

8 nnH Input Channel Status Bit Map (sum values from all six channels):

Channel 1 (L): off=00; on=01

Channel 2 (R): off=00; on=02

Channel 3 (C): off=00; on=04

Channel 4 (LFE): off=00; on=08

Channel 5 (LS): off=00; on=10

Channel 6 (RS): off=00; on=20

9 F7H EOX, End of System-Exclusive Message

Note: Inputs 3 and 4 only have input channels 1 (L) and 2 (R) associated with them.

Channels 3 (C), 4 (LFE), 5 (LS), and 6 (RS) are not physically present on inputs

3 and 4.
