Issue 1, March 2008 Model 761/771 User Guide

Page 10 Studio Technologies, Inc.

for Surround

Figure 4. Model 761 Digital Audio Inputs

SD–Primary

This input selection allows a 5.1 surround or 2-channel stereo audio source to be monitored.

Left Source: Channel 1, Surround A L/R input

Right Source: Channel 2, Surround A L/R input

Center Source: Channel 1, Surround A C/LFE input

LFE Source: Channel 2, Surround A C/LFE input

LS Source: Channel 1, Surround A LS/RS input

RS Source: Channel 2, Surround A LS/RS input

SD–SAP

This input selection allows a mono audio source to be monitored.

Source: Channel 1, Stereo A L/R input

SD–INTL

This input selection allows a mono audio source to be monitored.

Source: Channel 2, Stereo A L/R input

HD–Primary

This input selection allows a 5.1 surround audio source to be monitored.

Left Source: Channel 1, Surround B L/R input

Right Source: Channel 2, Surround B L/R input

Center Source: Channel 1, Surround B C/LFE input

LFE Source: Channel 2, Surround B C/LFE input

LS Source: Channel 1, Surround B LS/RS input

RS Source: Channel 2, Surround B LS/RS input

HD–SAP

This input selection allows a mono audio source to be monitored.

Source: Channel 1, Stereo B L/R input

HD–INTL

This input selection allows a mono audio source to be monitored.

Source: Channel 2, Stereo B L/R input

Director Cue

This input selection allows a 2-channel stereo audio source to be monitored using separate analog outputs.

L Source: Channel 1, Stereo C L/R input

R Source: Channel 2, Stereo C L/R input
